MODEL: REH 100SR (Wall to Wall Frameless Swing Door)
Swing In/ Swing Out/ Both Way Swing
Shower Screen Hinge
Brass Chromed or SUS304 Stainless Steel *Upon Request
Being tested by PSB TUV SINGAPORE 50,000 opening cycles
Door Space Allocation
REH Series available in three different shapes: Wall To Wall Shower Screen : Model REH100, REH300; Diamond Shape : Model REH200 and L Shape : REH400. REH Series is the most commonly seen for swing type shower. It comes complete with a full 304 stainless steel top header system and functional Stainless Steel Towel L-Handle. With its simplicity, it has become part of Shower Screen’s legend.
An ideal size for a shower area is minimum 4′ Length and 3′ Depth. Wall To Wall Shower Screen will cover the length to prevent water splashing around while you shower. To do this, you will need to measure the opening between the walls, you can do a quick measure by calculating how many floor tiles it contains between the two walls (Standard tile size is 8 inches, 1 foot and 2 feet). With this measurement, you will be able to choose whether you want 1, 2 or three panel Wall To Wall Shower Screen.The standard height for a Wall To Wall Shower Screen is 1800mm (6 feet), however we can custom made just any size to your liking.
All of our Shower Screen are custom made and our experienced technician will do a site consultation to work out the best solution for you.
For a quick tutorial to how to design a great Wall To Wall Shower Screen, we provide you some tips as below:-
>> If your measurement between the walls is less than 900mm, we will recommend just one piece of door only
>> If your measurement between the walls is between 900mm~1500mm, we will recommend one fix panel and one door panel, which side for the fix and door panel to be placed subject to site allocation for your shower head, bathtub, WC, Basin and floor leveling. This will apply to both Swing Door Type and Sliding Type.
>> If your measurement between the walls is more than 1500mm, we will recommend 1 fix panel at each side with the door at the center. This will become a three-piece Wall To Wall Shower Screen.
Glass Material Type
10MM Tempered Glass HydroSafe™ Glass
RELIANCE HOME Glass is safety glazing material, conforming to the requirements of ASTM C 1048, ANSI 97.1, BS 6206, etc.
RELIANCE HOME Tempered Glass is more resistant to thermally induced stress and can, therefore, resist thermal shock which can cause ordinary annealed glass to crack.
RELIANCE HOME Tempered Glass is approximately 4 to 5 times stronger than ordinary annealed glass. It has a higher bending strength and is more resistant to impact.
With our latest technology of HydroSafe™ Lamination, our glass is made water repellent and anti-explosion to provide you a safe, cleaning less shower screen experience!
